| FS2009USB Device Programmer - Product Change Notification |
Please note due to component obsolescence, this programmer has been re-designed.
The main change for the FS2009USB programmers is the mains power supply specification and DC jack connector.
The power supply has been updated to a newer version which is now 'Level 6 efficiency' compliant. This is now a legal requirement for use in the USA.
The Jack Socket Connector has been changed from a 2.5mm to a 2.1mm Jack Socket Connector.
|
|
FS2009USB
(cream case version)
|
FS2009USB
(new grey case version)
|
|
Specification
|
PSU-9V1700mA-2.5CP(UN)
9V Power Supply- Universal adaptor
Input: 110-240V AC,
Output: 9V DC reg.@1.7A
2.5mm tip, centre positive
|
PSU-9V1330mA-2.1CP
9V Power Supply- Universal adaptor
Input: 230V AC,
Output: 9V DC reg.@1.33A
Fitted with a 2.1mm centre +ve jack connector
|
|
Jack Socket Connector*
|
2.5mm
|
2.1mm
|
|
Power supply Efficiency rating
|
Level V
|
Level 6
(Compliant with new USA regulations)
|
|  |
|
| Reference: | JM161118-1 | | Date: | 16 November 2018 | | Author: | John Marriott | | Company: | Equinox Technologies |
|
