FlashPro-CC USB Gang Flash Programmer for the CCx series Chipcon products





The FlashPro-CC is a USB Flash Programmer for the CCx series Chipcon products from Texas Instruments.

Device SupportDownload Pic




Features



Features
  • No code size limitations
  • Lock security bit capability
  • Target device can be powered from the programming adapter (programmable Vcc from 2.2V to 3.6V step 0.2V) or from external source (2.2V to 3.6V)
  • Easy to use WindowsTM based software
  • Programmer accept TI (*.txt), Motorola (*.s19, *.s28, *.s37) and Intel (*.hex) data files for programming
  • Combine code files capability
  • Lock setup capability, useful in production
  • Unique IEEE address and serial number assign capability. Software package can assign and automatically increment IEEE address and serial number, model type and revision. Serial Number with or without an automatically inserted current date can be stored in the FLASH memory in HEX, BCD or ASCII format. The IEEE address and serial number can be assigned from the user defined list in the file
  • Log file capability allowing to review information about the flashed target devices
  • Multi-FPA API-DLL software package can control up to eight FlashPro-CC FPAs (working simultaneously) from other programs. Using eight FlashPro-CC FPAs the programming time of the 8 target devices is almost the same like programming time of the single target devices programmed from one FPA Perfect for production usage
  • Command line interpreter allows to use the Multi-FPA API-DLL software package and control up to eight FlashPro-CC FPAs (working simultaneously) from the command prompt or script file
  • Source code for the Multi-FPA API-DLL demo written in Visual C++.net
  • Programmer complies with FCC and CE requirements




Device Support (by family)



This product supports devices from the families listed below:

Texas Instruments:
  • Chipcon - CCXX Microcontroller Family



Please note:
Not all devices may be supported within a family.
Please see the Detailed Device Support List for a list of all devices which the product supports.




Ordering Information...




FlashPro-CC USB Gang Flash Programmer for the CCx series Chipcon products
USB Flash Programmer for the CCx series Chipcon products from Texas Instruments.
Manufacturer:  Elprotronic Inc.
Order Code:  ELP-FlashProCC
Quantity Price (GBP) [Excl. VAT]
1 - 9
235.00
10 and above
223.25

Availability:
2 in stock
Product Information
Product:  FlashPro-CC USB Gang Flash Programmer for the CCx series Chipcon products
Manufacturer:  Elprotronic Inc.
Order Code:  ELP-FlashProCC
Availability:  2 in stock
Price:   235.00 (GBP)
 [Excl. VAT]


Device Support
Device Support List


Downloads
Download View Downloads for this Product
