ISPnano-QC1 Connector Module for XMEGA PDI programming




The ISPnano-QC1 Connector Module features all the required circuitry and connectors for XMEGA PDI programming. It plugs into the 16-way IDC socket on the programmer.



Features



Main Features
Programmer compatability
Connecting to the programmer
Device Support

Main Features

  • Simple to fit, easily replaceable module which plugs into the 16-way 'Target ISP' connector on any ISPnano programmer.
  • Dedicated Atmel XMEGA PDI connector port
  • All XMEGA associated circuitry is incorporated on the module.
  • Module supports connection of BOTH an XMEGA PDI and SPI / JTAG Target System at the same time.
  • An in-line fuse in the 'EXT-VCC' line helps to protect the programmer from damage if an external Target Supply (with no current limit) is accidentally connected to one of the programmer I/O pins.
  • Modules can easily be replaced in case of damage.

Programmer compatability

This ISPnano-QC1 module is compatible with the following programmers:

  • ISPnano Series III
  • ISPnano Series III ATE

Connecting to the programmer

  • The ISPnano-QC1 module simply plugs into the 16-way IDC 'Target ISP' connector on any ISPnano programmer.
  • The module brings out the PDI / SPI / JTAG signals to a set of 12-way 'Quick Connect' connectors.
  • The 'Quick Connect' connectors allow wiring to a bed-of-nails fixture.




Device Support (by family)



This product supports devices from the families listed below:

Atmel (Microchip):
  • XMEGA AVR : Atmel XMEGA AVR - FLASH Microcontroller Family



Please note:
Not all devices may be supported within a family.
Please see the Detailed Device Support List for a list of all devices which the product supports.




Ordering Information...




ISPnano-QC1 Connector Module for XMEGA PDI programming
The ISPnano-QC1 Connector Module features all the required circuitry and connectors for XMEGA PDI programming. It plugs into the 16-way IDC socket on the programmer.
Manufacturer:  Equinox Technologies
Order Code:  ISPnano-QC1
Quantity Price (GBP) [Excl. VAT]
1 - 2
59.95
3 - 7
53.96
8 - 24
47.96
25 and above
41.97

Availability:
10 in stock
Product Information
Product:  ISPnano-QC1 Connector Module for XMEGA PDI programming
Manufacturer:  Equinox Technologies
Order Code:  ISPnano-QC1
Availability:  10 in stock
Price:   59.95 (GBP)
 [Excl. VAT]


Device Support
Device Support List


Downloads
Download View Downloads for this Product
