PropRPM - Rapid Prototyping Module for Parallax Propellor Chip |
|
|
|
|
|
| |
| The Propeller Rapid Prototyping Module is a high quality solution for Propeller Chip project prototyping. The ICs and LED bar are all socketed, making it easy to replace parts if necessary. An RS-232 Serial Interface means no extra hardware is required to program the Propeller if you have a DB-9 Serial Port on your PC. |
| |
|
|
|
 |
Key features |
|
- Propeller Chip P8X32A-D40 (DIP)
-
32KB EEPROM
-
5MHz quartz crystal
-
RS232 interface with MAX3232, Sub-D9 connector
-
Input voltage: 5..9VDC (2.1mm/5.5mm Plug)
-
3.3V low-dropout voltage regulator delivers up to 500mA for CPU and application
-
Power-LED
-
10 status LEDs (removable LED bar)
-
Reset switch
-
FBAS video output (RCA/Cinch connector)
-
large prototyping area (about half of board space)
-
4 mounting holes
-
Mech. dimensions: 130mm x 84mm (5.1" x 3.3")
|
|
Key Specifications |
|
- Power requirements: 5 to 9 VDC
-
Communication: Serial for programming
-
Dimensions: 5.11 x 3.3 x 0.61 in (130 x 84 x 15.54 mm)
-
Operating temp range:-32 to +158 °F (-0 to +70 °C)
|
| |
|  |
|
