Sollae CIE-H12 - Remote I/O Controller |
|
|
|
|
|
| |
The CIE-H12 is a remote I/O controller which can monitor digital inputs and and control digital output remotely over the Internet. As it supports only 2 input ports and 1 output port it is economical for a site that has 1 to 2 devices to control and monitor. CIE-H12 has various methods for I/O control such as HTTP, Modbus/TCP therefore can be used for various applications.
PLEASE NOTE:
The newer CIE-H12A product has a relay Wet in rating of 2.2 24V compared with 1.8 24V for the older CIE-H12 model.
|
| |
|
|
 |
Functional diagram |
|
|
|
|
Product highlights |
|
- Remote I/O controller
-
2 Digital Input ports (Dry contact 1 port, Wet contact 1 port)
-
1 Digital Output Port (Relay interface)
-
Modbus/TCP monitoring and surveillance
-
Monitoring and surveillance over the HTTP (available to upload user web pages)
-
Support of control of simple logic formula (available to operate autonomously)
-
Security Functions (IP filtering, password)
-
Support of DHCP, PPPoE (available for various dynamic IP environments)
-
Support of various host connection mode (TCP server, TCP client)
-
Multiple check functions of communication conditions (debugging mode, ezManager, TELNET)
-
Easy access by host name (DNS)
-
Available as a server by using the host name in the dynamic IP environment (DDNS)
-
IP address notification function (DDNS) useful in the dynamic IP environment
-
Support of the easy-to-use environment setting program for PC (ezManager)
-
Support of the Modbus/TCP program for integrated management of I/O equipment
-
Firmware-upgrading function over the LAN
-
Environmentally-friendly RoHS compliant
-
|
| |
 |
Sollae CIE-H12 - Remote I/O Controller
The CIE-H12 is a remote I/O controller which aids monitoring and controlling of 2 x digital inputs and 1 x output remotely over Ethernet (Internet).
