Sollae CSW-H85F Kit - Serial to WLAN Converter Kit |
|
|
|
|
|
| |
The CSW-H85 is a wireless LAN converter for serial devices. This compact product allows you to add wireless (WLAN) network communication capability to your existing serial devices. This can help shorten the development time of your end end-product and reduces the cost and risk of developing your own in-house WLAN solution.
The Kit version includes a universal 5V power supply and 9W serial cable. |
| |
| CSW-H85F was certified by FCC for US market. We recommend CSW-H85K for Europe as it has CE approval. |
| |
|
|
 |
Functional Diagram |
|
|
|
|
Highlights |
|
- Remote Monitor and Control serial devices
-
Supports IEEE802.11b/g
-
2dBi dipole antenna (various types of antennas available)
-
RS232 x 1 (up to 230,400bps, DB9-M interface)
-
Security function : IP filtering, Password
-
Flexible configuration and network communication by 'AT Commands' (patent)
-
Supports communication with variety of TCP/UDP hosts (TCP Server/Client, UDP)
-
Variety of communication status checkup(debugging mode, ezManager, Telnet)
-
Supports DHCP for dynamic IP environment
-
Supports 'DNS' protocol for simple connection to the Internet
-
Supports Dynamic DNS (DDNS) : available as Server with dynamic IP environment
-
IP Change Trap feature : useful with dynamic IP environment
-
Telnet COM Port Control Option (RFC 2217)
-
Easy configuration utility via network and serial for Windows OS (ezManager)
-
Virtual COM Port Redirector 'ezVSP' for Windows OS (provided free of charge)
-
Firmware is upgradable through the serial port
-
Environmentally-friendly RoHS compliant
|
|
Features / Specifications |
|
|
Serial Physical Interface |
|
Serial Interface |
1 x RS232 Port |
|
RXD, TXD, RTS, CTS, DTR, DSR |
|
¡¾15KV ESD Protection |
|
Connector |
1 x DB9M Connector |
|
Serial Port Property |
|
Baudrate |
300 bps ¡ 230400 bps |
|
Data Bits |
5, 6, 7, 8 bits |
|
Parity |
None, Even, Odd, Mark, Space |
|
Stop Bit |
1 , 1.5 , 2 |
|
Flow Control |
RTS/CTS Hardware |
|
Network Physical Interface |
|
Network Interface |
IEEE802.11b/g wireless LAN |
|
supplied with dipole 2dBi Antenna |
|
SMA Female Connector for antenna |
|
Software Functions |
|
Protocols |
TCP, UDP, IP, ICMP, ARP, TELNET |
|
DHCP, DNS, DDNS |
|
Telnet COM Port Control Option (RFC 2217) |
|
Security |
WEP |
|
IP & MAC filtering - Restrict host or network |
|
Password for Configuring |
|
Communication |
TCP server (T2S) |
|
Mode |
TCP client (COD) |
|
¡¡ |
TCP server/client with AT command (ATC) - Patent |
|
¡¡ |
UDP mode (U2S) |
|
Additional Functions |
Remote Debug Function |
|
Indicators(LEDs) |
|
Power |
Red |
|
Status |
Yellow, The current status |
|
wireless LAN Link |
Green |
|
wireless LAN RXD |
Yellow |
|
wireless LAN TXD |
Green |
|
Processors |
|
CPU |
ARM7 Core |
|
ROM |
512K bytes Flash Memory |
|
RAM |
128K bytes SRAM |
|
Management |
|
ezManager |
Configuration and Monitoring through ethernet and serial |
|
Telnet |
Telnet Login |
|
AT Command |
Configuring in ATC mode - Patent |
|
Supplementary Software |
|
ezManager - Configuration Tool for Windows through wLAN and serial |
|
ezVSP - Serial to Network Virtual Driver for Windows |
|
ezTerm - Simple TCP/IP Communication Test Tool |
|
wflash - Firmware Upgrade Utility for Windows through serial port |
|
Dimension |
|
Size |
93mm x 57mm x 24mm (without antenna) |
|
Body Netweight |
about 66g (without antenna), about 79g (with antenna) |
|
Operating Environment |
|
Input Voltage |
DC 5¡¾0.5V |
|
Power Consumption |
300mA Typical |
|
Operating Temperature |
¡¡ |
|
| |
|  |
|
