ISPnano - Active X Control - Software Development Kit |
|
|
|
|
|
| |
The 'Equinox Library' is a 32 bit COM Active X component that is written to allow developers and system integrators to write their own custom program which interacts with Equinox programmers. Active X is a Microsoft framework for defining re-usable software components in a programming language independent way. This means this control could be embedded into Microsoft Visual Studio.NET, Microsoft Office, National Instruments Labview and the like, so bespoke applications can be rapidly developed for specific needs.
|
| |
|
|
 |
ActiveX Features |
|
|
ActiveX is a powerful software utility which allows Equinox ISP Programmers to be controlled from a custom ‘Remote Application’ running under Microsoft Windows.
The main features of ActiveX control are:
- Allows any Equinox ISP Programmer to be remote controlled via a simple ActiveX control
- Suitable for interfacing to any application which executes under Microsoft Windows
- Supports controlling of both single programmers and also up to 32 networked
programmers
- Supports writing of a block of data from a file to the FLASH or EEPROM of a Target IC
- Supports reading of a block of data from the FLASH or EEPROM of the Target IC to a file
on the PC hard disk
- Supports uploading of pre-compiled standalone ‘Standalone Programming Projects’ to
a target programmer without requiring EQTools or the Project Upload Wizard utility.
- Supports execution of a specified ‘Programming Project’ which has already been
uploaded into the programmer ‘FLASH Memory Store’
- Supports programming of the ‘Configuration Fuses’ of the Target IC
- Supports programming of the ‘Security Fuses’ of the Target IC
- Supports controlling of Target Power (e.g. during functional test)
|
| |
|  |
|
