Xeltek Programming Adaptor: SA626A - 32-pin SOP/SOIC to 32-pin DIL |
|
|
|
|
|
| |
This Programming Adaptor is designed to convert any 32-pin SOP / SOIC package device into the corresponding 32-pin Dual-in-Line (DIL) package suitable for inserting into the ZIF socket of a Parallel Programmer.
Please note:
This adaptor features an 32-pin SOIC / SOP adaptor on the top but 32 DIL pins on the bottom.
Type: SOP/SOIC (open type)
Top PCB: SOP32/D32
Top Adaptor pin-out: SOP/SOIC32
Bottom PCB: B001 W*L(mm)=5,3 Pitch(mm)=0,65
Bottom Adaptor pin-out: DIL-32
Typical Device Support: Atmel, Catalyst, fairchild
Programmer supported: SP280U / 580U / 3000U / 8000U |
| |
|  |
|
