Programming Adapter: 8-pin DFN-S to DIL-8




This programming adapter converts a device in 8-Lead Plastic Dual Flat No Lead Package (MF) 6x5 mm Body (DFN-S) to a DIL-8 pin-out suitable for plugging into a ZIF socket of a programmer.

Top Package type:DFN-S
Description: 8-Lead Plastic Dual Flat No Lead Package (MF) 6x5 mm Body (DFN-S)
Bottom pin-out: DIL-8

Typical device support: Microchip24LC512 in DFN-S package

Please note:
This adaptor is an equivalent adaptor to the Xeltek SA683 DFN-8 adaptor.
The adaptor converts from DFN-S to 8-pin dual-in-line (DIL) and can therefore be plugged into any suitable programmer ZIF socket. As the adaptor simply maps from the QFN to the equivalent DIL-8 package, the user should select the 'DIP-8' device in the programming software.



Ordering Information...




Programming Adapter: 8-pin DFN-S to DIL-8
This programming adapter converts a device in 8-Lead Plastic Dual Flat No Lead Package (MF) 6x5 mm Body (DFN-S) to a DIL-8 pin-out suitable for plugging into the Dual-in-line (DIL) ZIF socket of any programmer.
Manufacturer:  Equinox Technologies
Order Code:  AD-8DFN-D3-ZL
Quantity Price (GBP) [Excl. VAT]
1 and above
312.65

Availability:
3 in stock
Product Information
Product:  Programming Adapter: 8-pin DFN-S to DIL-8
Manufacturer:  Equinox Technologies
Order Code:  AD-8DFN-D3-ZL
Availability:  3 in stock
Price:   312.65 (GBP)
 [Excl. VAT]
