EPSILON5MK4 - Portable ISP Programmer for Serial EEPROM Memory Devices |
|
|
|
|
|
| |
The Epsilon5 Portable USB ISP Programmer is a high-speed development / field / production programmer supporting most in-system programmable (ISP) microcontrollers from Atmel, Philips and Zensys. The programmer can be operated under PC control during development and for project configuration / uploading using the EQTools Toolsuite. For field / production applications the unit is designed to operate in ‘Standalone Mode’. A ‘Programming Project’ can be recalled from the on-board non-volatile FLASH memory and programmed into a Target System by pressing a single key. All the popular ISP headers are catered for including the new JTAG ISP Port required for fast programming of the Atmel ATmega AVR and AT91SAM7 families.
The Epsilon5(E2) is pre-loaded with the Serial I2C EEPROM Memory Device Library only - making it an ideal cost-effective solution for projects requiring this upgrade only. Further upgrades may also be purchased if required.
|
| |
| Ideal programmer for development, field service and production applications |
| |
|
|
|
 |
Supports PC Controlled and Standalone Programming |
|
- Development Mode - using Equinox Development Suite (EDS) under PC control
-
Standalone Mode - ideal for field or small-scale production use (no PC required)
|
|
Main features |
|
- Fastest programming times possible due to on-board data, high-speed SPI and JTAG port
- Supports programming of FLASH, EEPROM, FUSE bits, Security bits and RC Oscillator Calibration bytes
- 2Mbits of on-board non-volatile FLASH memory for user project storage (Standalone Mode)
- SCK2 Oscillator signal for externally clocking ATmega & ATtiny microcontrollers during programming
- On-board +12V Vpp generator for programming Atmel ATtiny11/12/15 microcontrollers in 'High voltage Serial Mode'
- JTAG Port - FAST ISP using JTAG algorithm (license upgrade)
|
|
Controlled / configured by Equinox EQTools Software |
|
- Equinox Development Suite (EDS)
- Project Builder - to create/edit Programming Projects
- Project Manager - to create and maintain Project Collections
- Project Upload / Download Utility - to upload projects to the programmer for use in Standalone Mode
|
|
Supports all popular ISP Headers to connect to the Target System |
|
- Atmel 10-way SPI Header (as per STK200 / STK500)
- Atmel 6-way SPI Header
- Equinox 10-way SPI header with support for Slave Select & SCK2
- Atmel 10-way JTAG header (as per Atmel JTAG-ICE)
- Equinox 10-way UART header for Atmel T89C51Rx2 (8051) and Philips P89C51 ISP FLASH microcontrollers
|
| |
| |
Device Support (by manufacturer) |
|
|
|
|
|
| This product supports devices from the manufacturers listed below: |
| |
Atmel Corporation
Dallas Semiconductor (Maxim)
Exel Semiconductor (Rohm)
Holtek Semiconductor
IC Microsystems
ISSI
Microchip
NXP (Philips)
ON Semiconductors (Catalyst)
Ramtron
Rohm
Seiko Instruments
STMicroelectronics
Xicor
|
|
The following are available as chargeable upgrades: JTAG In-System Programming support for the Atmel ATmega AVR Family and Atmel AT91SAM7 Upgrade Pack. See [Upgrades] tab.
|
| |
|
Please note:
Not all devices may be supported within a family.
Please see the Detailed Device Support List for a list of all devices which the product supports.
|
| |
This product has been discontinued. Please refer to the Replacement Product instead:
For further information about related products, please see the Overview Product.
|  |
