ISPjuno ARM - Portable ISP Programming System for ARM microcontrollers





Juno-ARM




Features



Programmer Features

  • Portable In-System (ISP) Programmer
  • Ideal for Field-service or Production programming applications
  • Supports In-system Programming (ISP) of many different programmable microcontrollers, serial EEPROM / FLASH memory devices and other custom devices
  • Supports programming via SPI, JTAG, SWD, I2C, UART, XMEGA PDI, ATtiny TPI, ams 1-wire, ams UART interfaces
  • Supports programming of devices between 1.8V and 5.0V
  • Supports ‘Standalone’ operation - no PC required after programmer has been configured with user projects
  • Capable of storing up to 64 completely independent ‘Standalone Programming Projects’.
  • High-speed USB connection to the PC (plus legacy RS232 COM port)
  • Programmer can power from PC USB port, target system or external power supply

Programmer in use




Device Support (by manufacturer)



This product supports devices from the manufacturers listed below:

Atmel (Microchip)
Dallas Semiconductor (Maxim)
Exel Semiconductor (Rohm)
Holtek Semiconductor
IC Microsystems
ISSI
Microchip
NXP (Philips)
ON Semiconductors (Catalyst)
Ramtron
Rohm
Seiko Instruments
Sigma Designs
STMicroelectronics
Xicor

The Device Support is different for each version of the ISPjuno programmer. Please see table above.



Please note:
Not all devices may be supported within a family.
Please see the Detailed Device Support List for a list of all devices which the product supports.




Ordering Information...




ISPjuno ARM - Portable ISP Programming System for ARM microcontrollers
ISPjuno ARM - Portable Production In-System (ISP) Programming system including support for many popular ARM microcontrollers. Standalone capability using LCD / keypad (64 projects) and USB / RS232 connectivity to PC.
Manufacturer:  Equinox Technologies
Order Code:  ISPjuno-ARM
Quantity Price (GBP) [Excl. VAT]
1 - 4
604.57
5 - 9
574.34
10 - 24
544.11
25 and above
513.88

Availability:
0 in stock
80 days delivery
Product Information
Product:  ISPjuno ARM - Portable ISP Programming System for ARM microcontrollers
Manufacturer:  Equinox Technologies
Order Code:  ISPjuno-ARM
Availability:  0 in stock
80 days delivery
Price:   604.57 (GBP)
 [Excl. VAT]


Device Support
Device Support List


Downloads
Download View Downloads for this Product
