Motorola - HC08 Microcontroller Welcome Kit




The new HC08 Welcome Kit again is a milestone in price performance ratio. The Welcome Kit PCB carries an HC908GP32, which is an 8 Bit controller belonging to the HC08 Family. The available 32KB Program Memory is many times larger than what could be found in the "good old" HC11 family. For the Program Memory now state-of-the-art Flash Technology is used.



Features



Module Specification:
  • Surface-mount QFP-44 package MCU MC68HC908GP32
  • All MCU Signals are available via two Header Connectors standard clock source: PLL using 32 kHz Clock XTAL
  • Serial Interface (PC or LCD connection) including RS232 Driver Indicator LED
  • 5V On-Board Voltage Regulator (requires 9VDC wall plug power supply)
  • Small wire wrap area for circuit extensions
  • Reset push button
  • Compact Size: 100mm x 60mm (approx. 4" x 2.5")

Debugging Support:
  • Complete Monitor Mode Interface circuit on-board
  • In-system Flash Programming supported
  • Quarz oszillator 9.8304 MHz (socketed)
  • Remote Power-On Reset via serial interface - no need to struggle with jumpers anymore!
  • Remote Break via serial interface - running user program can be stopped (invaluable aid during debugging!)

FL08 - FLASH Loader
  • The FL08 Flash Loader faciliates easy download to the target processor FLASH memory Occupies 3.5KB of the internal Flash Memory of the 'GP32'
  • Capable of downloading program files in Motorola S-Record format nearly ten times faster than the normal "Monitor Mode"!
  • To load a program with 12KB code takes less than seven seconds (compared to more than a minute in Monitor Mode!)




Device Support (by family)



This product supports devices from the families listed below:

Freescale:
  • HC08 FLASH Microcontroller Family



Device Support (by manufacturer / programming algorithm)




Motorola

BL - Boot Loader Algorithm:
HC08 FLASH Microcontroller Family:
MC68HC908GP32



Ordering Information...




Motorola - HC08 Microcontroller Welcome Kit
Motorola - HC08 Microcontroller Welcome Kit
Manufacturer:  Elektronikladen
Order Code:  EL-KIT08
Quantity Price (GBP) [Excl. VAT]
1 and above
52.99

Availability:
1 in stock
Product Information
Product:  Motorola - HC08 Microcontroller Welcome Kit
Manufacturer:  Elektronikladen
Order Code:  EL-KIT08
Availability:  1 in stock
Price:   52.99 (GBP)
 [Excl. VAT]
