HCS12 T-Board - Freescale HCS12 Microcontroller Evaluation and Training Module |
|
|
|
|
|
| |
The HCS12TB/STD is a versatile Microcontroller Evaluation and Training Module for the Freescale MC9S12DP512 microcontroller. The board features a surface mount version of the MC9S12DP512 processor with all I/O pins brought out to headers allowing for easy connection to external user peripherals. There are also a number of handy on-board peripherals including 8-way LED port, PWM Demo, RS232 port etc.
The module comes with the Twinpeeks Monitor Utility which supports uploading of user code from the PC via a Boot Loader which is pre-programmed into the microcontroller. The kit includes Module, RS232 Cable, TwinPEEKs-Monitor, Manual, CD-ROM. |
| |
|
|
|
 |
HCS12 T-Board Core Functions
|
|
- Motorola MCU MC9S12DP512 with TQFP112 Package (surface mounted)
-
16 MHz Crystal - up to 25 MHz Bus Clock using the PLL
-
PCB layout according to Motorola recommendation
-
Special LVI-Circuit (Reset Controller)
-
BDM-Connector for Download and Debugging
-
Compact Size: approx. 3.2" x 4"
|
|
Peripheral Functions on the HCS12 T-Board
|
|
- Serial Interface incl. RS232-Driver for connection to a PC
- 2nd serial Port for IF-Modules (RS232, RS485, LIN...)
- Connection of serial LC-Displays possible via IIC
- 8x Indicator-LED
- 8x DIP-Switch
- Two Push Buttons
- Analog Input with Potentiometer
- 2-Channel PWM-Visualisation using LED
- Acoustic Alarm (Beeper)
- High-Speed phys. CAN-Interface
- Reset Button
- 5V on-board Voltage Regulator, Power Jack Connector
- All MCU-Pins are accessible on four header connectors, layout compatible to Motorola EVB
- RAM add-on Board available (optional)
|
|
Motorola MC9S12DP512 Microcontroller features
|
|
- Motorola HCS12 16-Bit CPU
-
Programming Model and Instruction set is the same as the HC12
-
Bus Clock up to 25 MHz
-
112 Pins - up to 89 I/O-Pins
-
512 KB Flash Memory
-
4 KB EEPROM
-
14 KB RAM
-
2 x SCI - asynchronous Serial Interface (RS232, LIN)
-
3 x SPI - synchronous Serial Interface
-
IIC - Inter-IC-Bus
-
2 x MSCAN-Module (CAN 2.0A/B-compatible)
-
8 x 16-Bit Timer (Input Capture/Output Compare)
-
8 x PWM (Pulse Width Modulator)
-
16-Channel 10-Bit A/D-Converter
-
BDM - Background Debug Mode
-
Operating Voltage 5V
|
|
PCB Layout Overview |
|
|
This is the top view of the module.
|
| |
| |
Device Support (by family) |
|
|
|
|
|
| This product supports devices from the families listed below: |
| |
Freescale:
-
HC12 FLASH Microcontroller Family
-
HCS12 FLASH Microcontroller Family
|
| |
Device Support (by manufacturer / programming algorithm) |
|
|
|
|
| Motorola | | | | JTAG - In System Programming (ISP) via JTAG Debug Port (chargeable upgrade for Equinox Programmers): | | HC12 FLASH Microcontroller Family: | | MC9S12DP256 | | | | BL - Boot Loader Algorithm: | | HCS12 FLASH Microcontroller Family: | | MC9S12DP512 |
|  |
| Product Information |
| EL-HCS12TB/STD - Versatile Freescale HCS12 Microcontroller Evaluation and Training Module |
| Elektronikladen |
|
EL-HCS12TB/STD |
| Discontinued Product |
|
|
View Downloads for this Product
