TRP-C31S - Ethernet to RS-232/422/485 Converter |
|
|
|
|
|
| |
The TRP-C31S is a fast single-port RS-232 / RS-422 / RS-485 serial to Ethernet converter. It is designed to convert serial data from a synchronous RS-232 / RS-422 / RS485 port to a 10/100Mbps Ethernet network running using the TCP/IP protocol. This provides a straightforward method of connecting a remote serial peripheral eg. sensor, serial printer etc to an Ethernet network and then allows data to be read from / sent to this remote peripheral by sending data from a single PC over the Ethernet network. Typical applications include remote monitoring of serial sensors / transducers in factory control systems.
The TRP-C31S device can be operated via Windows, Linux and UNIX without the need to modify existing software. It is capable of operating in “Direct IP Mode”, “Virtual COM Mode”, and “Paired Mode” making it very versatile and suitable for most serial networking applications. It also offers a Heart Beat feature to ensure a reliable communicating connection. The TRP-C31S will work with 'Loop back Mode' where all data is sent back immediately. This feature makes the connection testing easy.
The industry standard DIN rail design enables fast and professional installation. |
| |
This product does NOT come with a serial cable or power supply. These items should be purchased separately. See Associated products.
If this product is out of stock, the TRP-C36S can be used as a replacement. |
| |
|
|
|
 |
Product Photo |
|
|
|
|
Features |
|
- Full compliance with the USB V1.0 and 2.0 specification
-
System gets 1 COM port when the converter is connected
-
Auto data format detecting
-
Auto direction flow control on RS-485
-
Auto baud rate switching from 300bps to 115.2 Kbps
-
256 byte buffer for upstream and downstream data flow
-
Direct power from USB port , no external power necessary
-
3000V DC isolated protection
-
Surge protection on RS422/485 data lines
-
Power/TX/RX mode LED indicator
-
DIN rail or panel mount support
-
Driver support: Windows 98/ME/2000/XP/CE3.0, and Linux, and Mac OS
|
|
Specifications |
|
- USB interface: Fully compliant with V1.0, 2.0 specification
-
USB to serial bridge controller; Prolific PL2303HX
-
RS-232 signal: 5 full-duplex (TXD, RXD, CTS, RTS, GND)
-
RS-422 signal: Differential 4 full-duplex wires (TX+, RX+, TX-, RX-)
-
RS-485 signal: Differential 2 half-duplex wires (D+, D-)
-
Data Format: Asynchronous data with all common combination of bits, parity, stop
-
Parity type: None, odd, even mark, space
-
Data bit: 5, 6, 7, 8
-
Stop bits: 1, 1.5, 2
-
Cable: USB type A to type B
-
Communication speed: form 300bps to 256Kbps
-
RS-422/485 line protection: Against surge, short circuit, and voltage peak
-
Transmission distance: RS-422/485 Up to 4000ft (1200M)
-
Connection type: Screw terminal accepts AWG #12~30 wires
-
Signal LED: Power on, TX, RX
-
Direct power from USB port
-
Power consumption: 1.2W
-
Isolation voltage: 3000V DC
-
Operating environment: 0 to 60℃
-
Storage temperature: -20 to 70℃
-
Humidity: 10-90% Non-condensing
-
Dimension: 151mm X 75mm X 26mm
-
Weight: 375g
|
| |
 |
TRP-C31S - Ethernet to RS-232/422/485 Converter
The TRP-C31S is a fast single port serial to Ethernet device, which allows instant conversion of data from RS-232/422/485 interfaces to a 10/100Mbps Ethernet network running at the TCP/IP protocol.
Discontinued Product
|
|  |
