ComPOD12 Overview Product - BDM ISP Programmer for Freescale HC(S)12





This page provides an overview of the In-System Programming (ISP) and In-system Debugging tools available for the Freescale HCS12 FLASH Microcontroller family.

The ComPOD12 BDM-Interface is a universal In-System Programming (ISP)device for downloading firmware / data to a Motorola HC(S)12 Target System. The programmer connects to the Target Device 'BDM Port' on the Target System using a 6-pin ribbon cable fitted with a BDM12 6-pin header connector as defined by Motorola. Power supply for the pod also comes over this connection from the target board.

The programmer driver software, StarProg, allows the Target Device FLASH and EEPROM memory areas to be programmed under PC control. The software makes use of the hardware interface ComPOD12 to access the target hardware. The connection to the PC is established via RS232.




Features



Overview
ISP (BDM) Interface
StarProg - PC Interface Software
Flexible Tool Files
StarProg for Production
PRO-Version provides extra features
ComPOD12 - Next Generation
Device Support

Overview
  • Programmer for In-System Programming (ISP) of Freescale HC(S)12 Microcontrollers
  • Supports programming of FLASH and EEPROM areas of Target Device
  • Powerful PC Driver Software - StarProg

ISP (BDM) Interface
  • Connects to BDM (Background Debug Mode) Port of Target Device
  • Programmer is connected to the target board using a ribbon cable with a BDM12 6-pin header connector as defined by Motorola.
  • Power supply for the pod also comes over this connection from the target board

StarProg - PC Interface Software

The StarProg Software is a simple IDE which allows the user to control the operation of the COMPOD Programmer from the PC. The user simply selects a specific Target Chip e.g. "MC9S12D64 internal Flash" from the software and can then perform Blank Check, Erase and Read / Write operation on this chip. The program can read Motorola S-Record or binary files.

Flexible Tool Files

The methods for programming the target memory are not built into the StarProg Software in a fixed, unalterable way. Instead of a static implementation, the algorithms are contained in separate Tool Files. This is the key to the unbeatable flexibility of StarProg! Even future HC(S)12 derivatives can easily be implemented as soon as silicon becomes available, just by adding the appropriate Tool File.

StarProg for Production

The special Production Mode (Blank/Program/Verify as an endless loop) of StarProg helps you to efficiently produce larger quantities of HC12 products.

PRO-Version provides extra features

The ComPOD12/PRO BDM-Interface provides all features of the standard version, plus a number of powerful extensions:

  • Higher RS232 interface speed: 115200 Baud
  • PC-connection via USB as an option (please add part number KABELUSB to your order)
  • Support of variable clock rates: 1, 2, 4 or 8 MHz
  • BDM-clock selectable (equals 2, 4, 8 or 16 MHz oscillator clock)
  • Advanced Reset-Sequencing (tolerating non-standard reset controllers)
  • Secure- and Unsecure-Function for HCS12 Controllers
  • Integrated update function allows replacement of Pod-Firmware
  • Attractive bundle pricing with NoICE12 Source Level Debugger

ComPOD12 - Next Generation

Our latest pod generation ComPOD12/NG provides the following advantages over the PRO version:

  • Support of Low-Voltage HCS12 types (VCC=3..5V)
  • Faster data transfer
  • BDM-clock continuously adjustable between 250kHz and 40MHz!




Device Support (by family)



This product supports devices from the families listed below:

Freescale:
  • HC12 FLASH Microcontroller Family



Device Support (by manufacturer / programming algorithm)




Motorola

JTAG - In System Programming (ISP) via JTAG Debug Port (chargeable upgrade for Equinox Programmers):
HC12 FLASH Microcontroller Family:
HC812A4 (+ external 29F400B FLASH) , HC812A4 (EEPROM), HC912B(C)32 (Flash and EEPROM) , HC912D60 (FLASH and EEPROM) , HC912D60A (FLASH) , HC912DG/DT128 (FLASH and EEPROM) , HC912DG/DT128A (FLASH)


Product Versions

ComPOD12 Next Generation - BDM ISP Programmer for Freescale HC(S)12 Microcontrollers
BDM12 In-System Programmer - Next Generation Version - for HC12 Microcontrollers with internal EEPROM and FLASH Memory. Supports Low Voltage devices, variable BDM speed, 115kbaud RS232, variable clock rates up to 8MHz, and non standard RESET circuit support.
Order Code:  EL-CP12/NG
Quantity Price (GBP) [Excl. VAT]
1 - 4
180.00
5 and above
171.00
10 - 24
162.00

Availability:
1 in stock
ComPOD12 Standard - BDM ISP Programmer for Freescale HC(S)12 Microcontrollers
BDM12 In-System Programmer - Standard Version - for Freescale HCS12 Microcontrollers with internal EEPROM and FLASH Memory.
Order Code:  EL-CP12/STD
Quantity Price (GBP) [Excl. VAT]
1 - 9
79.00
10 and above
75.05

Availability:
3 in stock




Device Support
Device Support List


Product Software View All
NOICE12 - Source Level Debugger for the Freescale HCS12 FLASH Microcontroller Family >>


Associated Products View All
Cables
USB to RS232 Convertor Cable - using the FTDI-Chip >>
Emulators
Softec - InDART One - In-Circuit Programmer/Debugger >>
Evaluation Modules (Microcontroller)
Motorola - HC12 Microcontroller Welcome Kit >>
Programmers
Softec - InDART One - In-Circuit Programmer/Debugger >>
Starter Systems (Microcontroller)
Motorola - HC12 Microcontroller Welcome Kit >>
Compilers / Assemblers
Imagecraft ICC12 Compiler - for Freescale HC(S)12 Microcontrollers >>
Key Products
Softec - InDART One - In-Circuit Programmer/Debugger >>
USB
USB to RS232 Convertor Cable - using the FTDI-Chip >>
