Main Features |
|
|
● Portable In-System (ISP) Programmer supporting Microchip AVR FLASH Microcontroller Families
● Supports most popular AVR programming interfaces including AVR ISP (SPI), JTAG, XMEGA PDI, ATtiny TPI, ATtiny / ATmega UPDI* (one wire)
● Ideal for Field-service or Production programming applications
● Supports ‘Standalone’ operation - no PC required after programmer has been configured with user projects
● Capable of storing up to 64 completely independent ‘Standalone Programming Projects’
● Supports programming of devices between 3.0V and 5.0V
● Interchangeable Target Interface Modules (TIM) available which interface to the target PCBA connector
● High-speed USB connection to the PC
● Programmer can be powered from: External power supply or External USB Power Pack
● Robust programmer design - all programmer I/O lines are fully ESD and over-voltage protected
*Note: The AVR - UPDI single-wire programming algorithm is still in development and is therefore not available at this time.
|
|
Standalone Mode operation |
|
|
● The Juno-MK2 programmer can be used in 'Standalone Mode' - no PC connection required
● Up to 64x independent 'Programming projects' for different programming jobs / devices can be pre-uploaded to the programmer before using in 'Standalone Mode'
● This makes the programmer ideal for Field-service or Production programming applications where multiple 'product firmware images' are required.
|
|
Programming Interfaces |
|
|
● Supports most AVR hardware interfaces / protocols including JTAG, XMEGA AVR PDI, ATtiny AVR TPI, ATtiny / ATmega AVR UPDI*, ATtiny AVR HV mode
● An additional target-specific ISP 'active cable' or 'Target Interface Module (TIM)' may be required to support certain programming interfaces.
● Individually configurable programmer I/O pins
● All programmer I/O lines are fully ESD and over-voltage protected
● Supports programming of target ICs between 3.0 and 5.0V.
● Programmable frequency generator output on SCK2 pin - supports external clocking of AVR microcontrollers to speed up programming
|
|
Supported Programmer Control Methods
|
|
|
The programmer supports the following control methods....
| Control method |
|
Control method overview |
Included as standard |
 |
Standalone Mode |
Keypad and LCD Display controlled (no PC) |
Included |
 |
Development Mode |
Controlled via PC Software - Equinox Development Suite (EDS) |
Included |
 |
Project Upload Mode |
PC Controlled - Project Upload Wizard utility |
Included |
 |
ASCII Text Communications Protocol |
USB VCP Serial control - chargeable upgrade |
UPGRADE |
 |
ConsoleEDS |
Console control application |
UPGRADE |
|
|
Target ISP Connectors |
|
|
|
|
Power and USB connectors |
|
|
|
|
Equinox Warranty |
|
|
|
|
Device Support Overview (Device Libraries) |
|
|
This programmer supports the following 'AVR microcontroller' Device Libraries as standard...

*Note: The new UPDI single-wire programming algorithm is still in development and is therefore not available at this time.
|
|
