ISPnano - 24xxx - Serial I2C EEPROM Memory Device Library





This License Upgrade is for In-System Programming (ISP) support for 24xxx I2C Serial EEPROM memory devices. This support will allow 24xxx I2C EEPROM memory devices to be programmed in-situ on a Target Board using the I2C 2-wire programming interface. Multiple I2C devices can be programmed on the same Target Support by simply selecting a different I2C address in the Programming Project.

The fastest possible programming speeds are guaranteed as the EEPROM data is stored locally within the programmer.

Standalone operation of the programmer (no PC) via single auto-program key is also possible making this solution ideal for high-volume production applications. The programmer can also be controlled from any Remote Application written in e.g.. C++, Labview, Visual Basic etc.




Features



Features
  • In-System Programming (ISP) support for 24xxx I2C Serial EEPROMs
  • Programmer uses the I2C 2-wire interface to program the device in-situ on a Target Board
  • Supports both 100 kHz and 400 kHz I2C operating frequencies
  • Multiple I2C Memories on the same I2C bus can be programmed
  • Fast programming times due to local storage of data to be programmed
  • Supports Program/Verify per page or Program entire device and then verify
  • Supports 3.0 to 5.0V Target Voltage operation
  • Standalone programmer operation (no PC required) is possible
  • PC software utility supports automatic serial number (up to 64-bit) generation and programming

Portable / Field Production ISP Programmers


Click the programmer picture for more information about the selected programmer

Portable Programmers
EPSILON5 MKIVFS2009 USBISPJUNOISPQUAD

Production ISP Programmers



Click on the picture of a programmer to view the full programmer description page.

Overview Title

ISPnanoS3ISPnano-GANGISPnanoS3-ATEISPnanoS4-ATE

ISPnano-MUXISPnano-MUX4ISPnano-MUX8




Device Support (by manufacturer)



This product supports devices from the manufacturers listed below:

Atmel (Microchip)
Dallas Semiconductor (Maxim)
Exel Semiconductor (Rohm)
Holtek Semiconductor
IC Microsystems
ISSI
Microchip
NXP (Philips)
ON Semiconductors (Catalyst)
Ramtron
Rohm
Seiko Instruments
STMicroelectronics
Xicor



Please note:
Not all devices may be supported within a family.
Please see the Detailed Device Support List for a list of all devices which the product supports.




Ordering Information...




ISPnano - 24xxx - Serial I2C EEPROM Memory Device Library
ISPnano - 24xxx - Serial I2C EEPROM Memory Device Library
Manufacturer:  Equinox Technologies
Order Code:  ISPnano-UPG16
Quantity Price (GBP) [Excl. VAT]
1 - 3
275.00
4 - 9
247.50
10 and above
206.25

Availability:
999 in stock

For further information about related products, please see the Overview Product.

Product Information
Product:  ISPnano - 24xxx - Serial I2C EEPROM Memory Device Library
Manufacturer:  Equinox Technologies
Order Code:  ISPnano-UPG16
Availability:  999 in stock
Price:   275.00 (GBP)
 [Excl. VAT]


Overview Product
24xxx - Serial I2C EEPROM Memory - Device Library - OVERVIEW >>
