- MCU: STM32F103RBT6 ARM 32 bit CORTEX M3™ with 128K Bytes Program Flash, 20K Bytes RAM, USB, CAN, x2 I2C, x2 ADC 12 bit, x3 UART, x2 SPI, x3 TIMERS, up to 72Mhz operation
-
standard JTAG connector with ARM 2x10 pin layout for programming/debugging with ARM-JTAG
-
USB connector
-
user button
-
RESET button
-
status LED
-
power supply LED
-
on board voltage regulator 3.3V with up to 800mA current
-
single power supply: takes power from USB port or extension connector pin
-
8 Mhz crystal oscillator
-
32768 Hz crystal and RTC backup battery connector
-
extension headers for all uC ports
-
PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
-
Dimensions: 61x 34mm (2.4 x 1.3")
-
Distance between the exntension connectors: 25.4 mm (1")
|
