FS2000A - Portable ISP Programmer for Atmel AVR and AT89S Microcontrollers





The FS2000A programmer supports high-speed ISP of most Atmel AVR and AT89S FLASH microcontrollers. The programmer can be utilised as standard in 'Standalone Mode' i.e. not connected to a PC making it ideally suited to the field-service and/or Production ISP environments. The operator simply selects one of the 64 projects stored locally on the programmer and then presses a single 'Auto-program' button to program the target device. Each project is individually version controlled and CRC checked ensuring that the correct firmware is programmed every time.




Please consider the FS2003 Programmer for any new Programming Application.



Features



Overview
Programming Modes
Standalone Programming Mode
Development Mode (EDS)
In-System Programming Headers
Power supply options
EW2019
Device Support

Overview
  • Portable In-System Programmer for Atmel Microcontrollers
  • Ideal for development, Production or Field use
  • Supports 'Standalone' operation i.e. no PC required after programmer has been configured
  • Very fast programming speeds suitable for high-throughput production environments
  • Robust SPI I/O stage
  • Programmable frequency generator output on SCK2 pin - supports external clocking of ATmega,  and ATtiny AVR devices to speed up programming
  • Programmer firmware is field upgradeable to cater for future algorithms

Programming Modes
  • Standalone Mode - Keypad and LCD controlled (no PC)
  • Development Mode - Controlled via PC Software - Equinox Development Suite (EDS)
  • Project Upload Mode - PC Controlled

Standalone Programming Mode

  • On-board 4Mbits FLASH Memory Store - supports storage up to 64 independent Programming Projects
  • Simple selection of required project using LCD and keypad
  • Project are uploaded to the programmer using EQTools - Project Upload Wizard
  • Each project name is version controlled showing the project name, date, firmware revision and build date. e.g. myproject-240402-2.3.4.12
  • Operator can not inadvertently change the programming data or settings
  • Single key auto-program mode

Development Mode (EDS)
  • Programmer is controlled from the PC via EQTools - Equinox Development Suite (EDS) software
  • Ideal for use in a Development Environment
  • Supports manual writing / reading of FLASH / EEPROM memory areas
  • Supports manual writing / reading of Fuses and Security Fuses
  • All projects can be developed and tested on a real device before uploading a Programming Project to the programmer

In-System Programming Headers
  • Equinox 10-way ISP Header
  • Atmel 10-way ISP Header
  • A convertor from the Equinox 10-way to Atmel 6-way is available as an optional extra.
  • A convertor from the Equinox 10-way to Atmel 10-way JTAG connector is available as an optional extra.

Power supply options
  • Programmer can power the Target System (+5V only - not controllable)
  • Target System can power the Programmer via ISP Cable (+5V only)
  • Programmer can be powered at +5V and the Target System can be Independently Powered at 3.0 - 5.0V. (Vcc Switch in '0' position)
  • Programmer internal electronics must be powered at 5.0V DC
  • Programmer comes complete with 9V DC power supply which is regulated by the FS2000A to 5.0V.

EW2019

Come and talk to us at the show...

EW2019

John Marriot will be attending the exhibition, should you want to arrange a meeting with him whilst he's there please send an email to sales@equinox-tech.com




Device Support (by family)



This product supports devices from the families listed below:

Atmel (Microchip):
  • AT89(L)S - 8051 FLASH Microcontroller Family
  • AT90CAN - AVR with on-chip CAN : AVR microcontroller with on-chip CAN
  • AT90PWM - AVR Microcontroller Family
  • AT90S AVR  - FLASH Microcontroller Family
  • AT90USB - AVR FLASH Microcontroller Family
  • ATmega AVR - FLASH Microcontroller Family
  • ATmegaxxxP 'PICO Power' AVR Microcontroller Family
  • ATtiny AVR - FLASH Microcontroller Family

Please refer to EQTools for the most up-to-date Device Support List.



Please note:
Not all devices may be supported within a family.
Please see the Detailed Device Support List for a list of all devices which the product supports.




Ordering Information...




FS2000A - Portable ISP Programmer for Atmel AVR and AT89S Microcontrollers
Portable High-speed In-System Programming (ISP) Solution for Atmel AVR and AT89S Microcontrollers. (Supplied with Universal Power Supply - UK / Euro / US Asia)
Manufacturer:  Equinox Technologies
Order Code:
Equinox:  FS2000A(UN)
 483-1001-ND
Discontinued Product

This product has been discontinued. Please refer to the Replacement Product instead:

FS2009 - Portable high-speed multi-project USB In-System (ISP) Programmer

Manufacturer:  Equinox Technologies
Order Code:
Equinox:  FS2009(UN)
 483-1020-ND
 1695684
Discontinued Product


Product Information
Product:  FS2000A - Portable ISP Programmer for Atmel AVR and AT89S Microcontrollers
Manufacturer:  Equinox Technologies
Order Code:
Equinox:  FS2000A(UN)
 483-1001-ND
Discontinued Product


Discontinued Product
This product has been discontinued and replaced by the following product(s):
FS2009 - Portable high-speed multi-project USB In-System (ISP) Programmer >>
